Additional information
| SIZE | 110 |
|---|---|
| Torque Rating – Nm | 160 |
| Allow Speed RPM | 5300 |
| D1 Max Bore – MM | 48 |
| D2 Max Bore – MM | 38 |
| D - MM | 110 |
| L1 - MM | 40 |
| L2 - MM | 40 |
| D1 - MM | 86 |
| D2 - MM | 62 |
| L3 - MM | 20 |
| L4 - MM | 34 |
| S - MM | 3 |
| WEIGHT - KG - part 1 | 1.95 |
| WEIGHT - KG - part 2 | 1.38 |
| WEIGHT - KG - part 3 | 1.97 |
| Moments of inertia - kgm2 | 0.003 |
| axial ∆ K - mm | 0.2 |
| radial ∆ K - mm | 0.2 |
| angular ∆ K - ° | 0.1 |
