Description

MTM T7FC 055 – Tapered Roller Bearing

Single-row tapered roller bearings are engineered to handle both radial and axial loads while maintaining low friction during operation. The inner ring, along with the rollers and cage, can be installed separately from the outer ring. Their separable and interchangeable design makes mounting, dismounting, and maintenance easier. When two single-row tapered roller bearings are mounted against each other with a preload, a highly rigid bearing assembly can be achieved.

Key Features:

• High capacity for radial and axial loads

• Supports axial loads in one direction

• Low friction for extended service life

• Separable and interchangeable components for easy maintenance

📋 Specifications

• Bore diameter (d): 55 mm

• Outer diameter (D): 115 mm

• Overall width (B/T): 34 mm

• Precision class: Class 6 (P6) → High accuracy, suitable for high-speed or precision applications

• Weight: 1.6 kg

🔧 Typical Applications

• Automotive gearboxes

• Shafts and transmission systems

• Industrial motors and heavy machinery

🔒 Locking system (for 55 mm shaft):

• Lock Nut: KM 11

• Lock Washer: MB 11
